Applications

  • Advertising Specialties, Vehicle Signage, Shelf and Bin Marking, Craft and Hobby, Photo Mounting, P.O.P. Displays, Display Boards, Signage, Automobile Paint Masking, Nameplates, Novelties, Premiums, Menu Boards, Sales Promotions, Toys, Visual Aids, Graphics

Part No.



10 ft.Ig.

25 ft.Ig.

50 ft. Ig.

3 Rolls
(50 ft)/ea

> 200 ft
-----------------          . 015" THICK x 24" Width
ZG1524P Uncoated $ 26.00 $ 45.00 $ 69.00 $ 64.00 Call
ZG1524GW Gloss White $ 33.00 $ 62.00 $ 106.00 $ 100.00 Call
ZG1524A Indoor PSA $ 33.00 $ 64.00 $ 99.00 $ 95.00 Call
ZG1524C Colors $ 36.80 $ 72.50 $ 126.00 $ 120.00 Call
----------------            .020" THICK x 24" Width
ZG2024P Uncoated $ 29.00 $ 56.00 $ 88.00 $ 83.00 Call
ZG2024GW Gloss White $ 35.00 $ 66.00 $ 111.00 $ 104.00 Call
ZG2024A Indoor PSA $ 35.00 $ 67.50 $ 115.00 $ 110.00 Call
ZG2024C Colors $ 38.80 $ 79.50 $ 137.00 $ 130.00 Call
--------------               .025" THICK x 24" Width
ZG2524P Uncoated $ 32.00 $ 52.25 $ 95.00 $ 90.00 Call
ZG2524GW Gloss White $ 37.00 $ 65.00 $ 118.00 $ 112.00 Call
ZG2524A Indoor PSA $ 38.00 $ 67.65 $ 123.00 $ 115.00 Call
ZG2524C Colors $ 43.00 $ 82.50 $ 150.00 $ 140.00 Call
------------                . 030" THICK x 24" Width
ZG3024P Uncoated $ 36.00 $ 70.00 $ 130.00 $ 124.00 Call
ZG3024GW Gloss White $ 38.00 $ 75.00 $ 121.00 $ 119.00 Call
ZG3024A Indoor PSA $ 38.00 $ 77.50 $ 137.00 $ 130.00 Call
ZG3024AO Outdoor PSA $ 56.00 $ 120.00 $ 220.00 $ 209.00 Call
ZG3024C Colors $ 40.00 $ 88.50 $ 155.00 $ 140.00 Call
------------             . 045" THICK   x 24" Width
ZG4524P Uncoated $50.00 $95.00 $260.00 $246.00 Call
ZG4524GW Gloss White $55.00 $107.00 $292.00 $275.00 Call
ZG4524A Indoor PSA $55.00 $107.00 $292.00 $275.00 Call
ZG4524C Colors $70.00 $147.00 $400.00 $374.00 Call
------------           . 060" THICK   x 24" Width
ZG6024P Uncoated $65.20 $140.00 $236.00 $233.00 Call
ZG6024GW Gloss White $78.00 $150.00 $258.00 $249.00 Call
ZG6024A Indoor PSA $72.00 $150.00 $258.00 $249.00 Call
ZG6024AO Outdoor PSA $77.00 $162.00 $296.00 $280.00 Call
ZG6024C Colors $80.00 $166.00 $302.00 $286.00 Call
  • 39.5" Width is avaliable.

Finishing Ideas

  • Die Cut, Pad Print, Thermograph, Hand Letter, Screen Print, Stencil, Adhere Vinyl Lettering and Graphics

Dimensions

  • Standard Width: 24.375" (+/- .060")
  • Standard Lengths: 10, 25, and 50 ft. rolls
  • Standard Thicknesses: .015" to .060" (+/- .003") - .015" and .020" - Ideal for advertising specialties (lowest cost and weight). .030" - Recommended for vehicle signage; strong enough for wind sheer at highway vehicle speeds.
  • Pre-cut sign blanks available from stock (12" x 24.375" or 18" x 24.375"). .045" and .060" - Customer preference for applications requiring higher strength and thicker profile.
  • Thinner sheeting available for custom applications. Please call for more information.

Laminations - A variety of high quality laminations are available that are typically applied to the non-magnetic (weak) side of the sheeting.

Vinyl Features

  • High-quality top coat allows superior adhesion of most screen print inks and lettering enamels.
  • Will not crack when material is flexed.
  • Excellent weather resistance to rain, snow, and summer heat.

Vinyl Choices - gloss white, high gloss white and UV ink gloss white, red, orange, yellow, green, blue, purple, silver, black, gold, brown, ivory, chrome, brushed gold, brushed silver, holographic celebration and holographic prism.

Uncoated/Plain - no vinyl, no adhesive
(dark brown on both sides)
See tables below for additional size and weight specifications.


Adhesive Choices
  • Rubber-Based Craft Adhesive (indoor and craft applications)
  • Rubber-Based High-Tack Adhesive (premium)
  • Acrylic-Based Adhesive (for outdoor applications or adhering to plastics or soft vinyls)


Custom Laminations Available

  • Write-on/Wipe-off (white)
  • Vinyl on magnetic side with adhesive on reverse.
  • High Gloss White Paper; less expensive than vinyls, accepts larger variety of inks, can write on with ink pens, easier to get crisp die cut, for indoor applications only.

Strength - The thicker the flexible material, the stronger the magnetic strength. Under ideal test conditions, magnetic sheeting can be rated in approximate pounds of pull per square foot. Peel strength is not rated.

Thickness
Approximate Pull Per Sq. Ft.
.015"
40 pounds
.020"
60 pounds
.030"
85 pounds

Minimum orders may apply depending on thickness and/or color.


Care and Maintenance of Vehicle Signs

  • Vehicle surface and magnetic side of sign should be cleaned, dried and waxed.
  • Sign area should not have molding or air gaps.
  • Vehicle and sign surfaces should be cleaned weekly.
  • Remove sign when cleaning vehicle.
  • Use mild detergent and warm water to clean magnetic sign.

We supply the magnetic material, you have it designed and printed to make durable, eye-catching signs for business or events.




Custom Cutting Capabilities - Our precision equipment will cut any roll of flexible sheeting material to the size your application requires. This is achieved using a combination of state-of-the-art computerized slitting and cut-off equipment. Please consult your sales specialist for quotes and to have cut piece yield estimates calculated.

Cutting - High speed cutting equipment cuts full rolls to sizes as small as 2" x 2" with a tolerance of +/- .060" on either dimension. Tolerances will vary depending on length of cut

Slitting - Slitting wheels slit a full roll into several rolls of various widths as narrow as 2", with a precision of +/- .060".

Die Cutting - Custom and standard shapes available.
